UTEPO UOF7201GE

Item

Description

Power

Power Supply

Power Adapter

Voltage range

DC12V~24V

Consumption

＜3W

Ethernet Port Parameter

Ethernet Port

Ethernet port:10/100/1000Mbps

Transmission Distance

Ethernet port:0～150m

Fiber Port Parameter

Fiber Port

LC Port, SFP Optical Module, Single Fiber or Dual

Bandwidth

1.25Gbps

Transmission Distance

Depend on SFP module performance

Network Exchange Specification

Ethernet standard

IEEE802.3、IEEE802.3u、IEEE802.3ab/z、

10/100/1000BASE-TX and 1000BASE-FX、

IEEE802.3 X.

Status Indicator

Power indicator light

1 Red

Network indicator light

1 Green on RJ45 Socket

Fiber indicator light

3 Green (Link,SD,FED)

Protection Level

ESD

3 level,Standard:IEC61000-4-2

Protection level

3 level,Standard: IEC61000-4-5

Operation Environment

Working Temperature

-40℃~75℃

Storage Temperature

-40℃~85℃

Humidity (non-condensing)

0~95%

Mechanical

Dimension (L×W×H)

26mm×71mm×94mm

Material

Aluminum Alloy

Color

Black

Weight

160g
