Mobilaus ryšio funkcijos | |
Mobilaus ryšio modulis | 4G (LTE) – Cat 6 up to 300 Mbps, 3G – Up to 42 Mbps |
SIM keitimas | 2 SIM cards, auto-switch cases: weak signal, data limit, SMS limit, roaming, no network, network denied, data connection fail |
Statusas | Signal strength, SINR, RSRP, RSRQ, Bytes sent/received, connected band, carrier aggregation, IMSI, ICCID |
SMS | SMS status, SMS configuration, send/read SMS via HTTP POST/GET, Email to SMS, SMS to Email, SMS to HTTP, SMS to SMS, SMS auto reply |
USSD | Supports sending and reading Unstructured Supplementary Service Data messages |
Baltasis/juodasis sąrašas | Operator black/white list |
Multiple PDN | Possibility to use different PDNs for multiple network access and services |
Juostos valdymas | Band lock, Used band status display |
APN | Auto APN |
Tilto rėžimas | Direct connection (bridge) between mobile ISP and device on LAN |
Etherneto funkcijos | |
WAN | 1 x WAN port (can be configured as LAN) 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
LAN | 3 x LAN ports, 10/100/1000 Mbps, compliance with IEEE 802.3, IEEE 802.3u, 802.3az standards, supports auto MDI/MDIX crossover |
Įvestis/išvestis | |
Įvestis | 1 x Digital Input, 0 – 6 V detected as logic low, 8 – 30 V detected as logic high |
Išvestis | 1 x Digital Output, Open collector output, max output 30 V, 300 mA |
Įvykiai | SMS, Email, RMS |
Galia | |
Sujungimas | 4 pin industrial DC power socket |
Įvesties įtampos diapozonas | 9 – 50 VDC, reverse polarity protection, voltage surge/transient protection |
PoE | Passive PoE. Possibility to power up through LAN port, not compatible with IEEE 802.3af, 802.3at and 802.3bt standards |
Galios suvartojimas | 9 W Max |
Fizinė specifikacija | |
Korpuso medžiaga | Aluminium housing with DIN rail mounting option |
Matmenys (W x H x D) | 115 x 44.2 x 95.1 mm |
Svoris | 455 g |
Montavimo funkcijos | DIN rail, flat surface placement |
Aplinkos įtaka | |
Temperatūros įtaka | -40 C to 75 C |
Atsparumas drėgmei | 10 % to 90 % non-condensing |
Apsauga | IP30 |
