Hikvision dome DS-2CD2686G2-IZS (balta, 8 MP, 60 m. IR, AcuSense)
449,73€(Kaina be PVM)544,17€(Kaina su PVM)
- MP (MegaPixel): 8 MP
- Objektyvas: 2.8 – 12 mm, horizontalus FOV: 108° – 46°
- Technologija: AcuSense
- Integruotas mikrofonas: Ne, yra mikrofono įvestis
- Integruotas garsiakalbis: Ne, yra garso įvestis
- Naktinis pašvietimas: 60 m. IR
- Vieta microSD talpai: Taip, 256GB
- Darbo sąlygos: -30 °C iki 60 °C
- Saugos lygis: IP66
- Vaizdo suspaudimas: H.265+
- WiFi: Ne
- Laikiklis/bazė (papildomai): DS-1476ZJ-SUS
- Lauko/vidaus: Lauko
| Pavadinimas | Aprašymas |
| Sensorius | 1/1.8″ Progressive Scan CMOS |
| Min. apšvietimas | Color: 0.003 Lux @ (F1.6, AGC ON), 0 Lux with IR |
| Užrakto greitis | 1/3 s to 1/100,000 s |
| Išlaikymas | Yes |
| Diena/naktis | IR Cut Filter |
| Kampo valdymas | Pan: 0° to 355°, tilt: 0° to 90°, rotate: 0° to 360° |
| WDR | 120 dB |
| Objektyvas | 2.8 to 12 mm |
| Diafragma | F1.4 |
| FOV | Horizontal FOV: 108.1° to 45.5° , vertical FOV: 58.4° to 25.7° , diagonal FOV: 127.3° to 52.1° |
| Montavimas | Φ14 |
| IR atstumas | Up to 60 m |
| Bangos ilgis | 850 nm |
| Maks. raiška | 3840 × 2160 |
| Pagrindinis srautas | 50Hz: 20fps (3840 × 2160, 3072 × 1728), 25fps (2688 × 1520,1920 × 1080, 1280 × 720) 60Hz: 20fps (3840 × 2160, 3072 × 1728), 30fps (2688 × 1520,1920 × 1080, 1280 × 720) |
| Antrinis srautas | 50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Tretinis srautas | 50Hz: 25fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (1280 × 720, 640 × 480, 640 × 360, 320 × 240) |
| Vaizdo suspaudimas | Main stream: H.265+/H.264+/H.265/H.264 Sub-stream: H.265/H.264/MJPEG Third stream: H.265/H.264 |
| H.264 tipas | Baseline Profile/Main Profile/High Profile |
| H.265 tipas | Main Profile |
| Vaizdo bitų greitis | 32 Kbps to 16 Mbps |
| SVC | H.264 and H.265 encoding support |
| Garso suspaudimas | G.711/G.722.1/G.726/MP2L2/PCM/MP3 |
| Garso bitų greitis | 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)/8Kbps-320Kbps(MP3) |
| Aplinkos triukšmo šalinimas | Yes |
| Garso ėminių dažnis | 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Pagridniniai įvykiai | Motion detection, video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error), scene change detection |
| Papildoma apsauga | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (Human&Vehicle classification) |
| ROI | 1 fixed region for main stream, sub-stream and third stream |
| Susiejimo metodas | Upload to FTP/NAS/memory card, notify surveillance center, send email, alarm output, audible warning, trigger capture |
| Vaizdo gerinimas | BLC, HLC, 3D DNR |
| Vaizdo nustatymai | Saturation, brightness, contrast, sharpness, AGC and white balance adjustable by client software or web browser |
| Diena/naktis perjungimas | Day/Night/Auto/Schedule/Triggered by Alarm In |
| Tinklo saugykla | microSD/SDHC/SDXC card (256 GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Protocolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, SSL/TLS |
| API | ONVIF (PROFILE S, PROFILE G), ISAPI, SDK |
| Apsauga | Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for ONVIF, TLS1.2 |
| Transliacija | Up to 6 channels |
| User/Host | Up to 32 users, 3 levels: administrator, operator and user |
| Programinė įranga | iVMS-4200, Hik-Connect, Hik-Central |
| Naršyklė | Plug-in required live view: IE8+, Chrome 41.0-44, Firefox30.0-51, Safari8.0-11 Plug-in free live view: Chrome 57.0+, Firefox 52.0+ |
| Ryšio sertifikatai | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Garsas | 1 audio input (line in), two-core terminal block; 1 audio output(line out), two-core terminal block |
| Pavojaus signalai | 1 alarm input, 1 alarm output (max. 24 VAC/24 VDC@500 mA) |
| Vidinė atmintis | Built-in micro SD slot, up to 256 GB |
| Kalbos | 32 languages English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil) |
| Pagrindinės funkcijos | Anti-flicker, three streams, heartbeat, mirror, privacy masks, pixel counter |
| Perkrovimas | Reset via reset button on camera body, web browser and client software |
| Startas ir darbo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Saugyklos darbo sąlygos | -30 °C to 60 °C (-22 °F to 140 °F), humidity 95% or less (non-condensing) |
| Maitinimas | 12 VDC ± 25%, two-core terminal block; reverse polarity protection; PoE (802.3at, class 4) |
| Galia ir srovė | 12 VDC, 1.12 A, max. 13.5 W; PoE (802.3at, 42.5 V to 57 V), 0.5 A to 0.3 A, max. 15 W |
| Medžiaga | Metal |
| Išmatavimai | Camera: Φ 144 × 333 mm (Φ 5.7″ × 13.1″) With package: 385 × 190 × 180 mm (15.2″ × 7.5″ × 7.1″) |
| Svoris | Camera: approx. 1430 g (3.2 lb.) With package: approx. 2490 g (5.5 lb.) |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1) |
| Aplinkosauga | CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Apsauga | Ingress protection: IP66 (IEC 60529-2013), IK10(IEC 62262:2002) |
| Svoris | 1,917 kg |
|---|---|
| Gamintojas |
