Hikvision automobilinė dome kamera DS-2XM6222G1-ID(AE) F2.8
Preliminari mėnesinė įmoka nuo 13,75€ / 36 mėn.
291,22€(Kaina be PVM)352,38€(Kaina su PVM)
| 2MP | |
| 2.8/4/6 mm fiksuotas objektyvas | |
| 120 dB WDR | |
| IP68 | |
| IR pašvietimas iki 30m |
Turime
Kamera
| Užrakto greitis | 1/3 s to 1/100,000 s |
| P/N | PAL: 25fps NTSC: 30fps |
| Day & Night | IR Cut Filter |
| Kampo keitimas | Pan: -20° to 0°, Tilt: -15° to 25° |
| Baltos spalvos balansas | Support 4 white balance configurations: fluorescent lamp, incandescent lamp, warm lamp and natural light; Support manual/automatic white balance adjustment. |
Lęšis
| FOV | 2.8mm/4mm/6mm |
| Focal Length & FOV | 2.8mm: horizontal FOV 105°, vertical FOV 56°, diagonal FOV 126° 4mm: horizontal FOV 87°, vertical FOV 44°, diagonal FOV 104° 6mm: horizontal FOV 53°, vertical FOV 28°, diagonal FOV 62° |
| Lęšio montavimas | M12 |
| Fokusavimas | Manual focus |
| Max. Aperture | 2.8/4/6mm : F1.6 |
Apšvietimas
| Papildomo apšviešimo tipas | Infrared fill light lamp |
| Išmanus papildomas apšvietimas | Support |
| IR bangos ilgis | 850 nm |
| IR distancija | Up to 10 m |
Vaizdas
| Maks. rezoliucija | 1920 x 1080 |
| Pagrindinis srautas | 50Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720) 60Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720) |
| Antrinis srautas | 50Hz: 25 fps (704 x 576, 640 x 480, 352 x 288, 320 x 240) 60Hz: 30 fps (704 x 576, 640 x 480, 320 x 240) |
| Trečias srautas | 50Hz: 25 fps (1920 x 1080, 1280 x 960, 1280 x 720) 60Hz: 30 fps (1920 x 1080, 1280 x 960, 1280 x 720) |
| Vaizdo suspaudimas | Main stream: H.264, H.265, H.264+, H.265+ Sub-stream: H.264, H.265, MJPEG, H.264+, H.265+ Third stream: H.264, H.265 ,H.264+, H.265+ |
| Vaizdo bitų greitis | 256 Kbps to 12 Mbps |
| H.264 tipas | BaseLine Profile/Main Profile/High Profile |
| H.265 tipas | Main Profile |
| Bitų greičio kontrolė | Constant Bit Rate, Variable Bit Rate |
| Srauto tipas | Main stream, sub stream, third stream |
| Scalable Video Coding (SVC) | H.264 and H.265 encoding
|
| Region Of Interest (ROI) | Support 2 fixed region for (main/sub) stream |
Garsas
| Garso suspaudimas | G711U, G711A, G726, AAC, G722, PCM, AAC |
| Garso bitų greitis | 64 Kbps |
| Garso atrankos dažnis | 16 kHz |
| Pašalinių garsų šalinimas | Support |
Internetas
| Protokolai | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, Email ,RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, ICMP 802.1X, QoS, IPv6, Bonjour, ISUP5.0 |
| Tiesioginis vaizdo žiūrėjimas | Up to 8 channels |
| API | ONVIF (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| User Management | Up to 16 users, 3 levels: Administrator, Operator and User |
| Naršyklė | IE8+, Chrome45+, Edge41+, Firefox45+ |
Nuotrauka
| Wide Dynamic Range (WDR) | 120 dB |
| Nuotraukos nustatymai | Support rotation mode. Brightness, contrast, saturation and sharpness can be adjusted by browser and client software. |
| Diena/Naktis režimas | Day/Night/Auto/Schedule |
| SNR | > 50 dB |
| Nuotraukų pagražinimas | BLC,HLC, 3D DNR |
| Privatumo kaukė | Enables configuration, and supports drawing of up to 4 areas |
| Nuotraukos perdanga | Support image overlay, uploading images, enabling, coordinates, etc. |
| Tikslinis apkarpymas | Support (only the third stream) |
| Backlight Compensation(BLC) | Support up, down, left, right, center and custom backlight compensation adjustment |
Sąsaja
| Vaizdo išvestis | Not supported |
| Interneto sąsaja | -ID: 1 RJ45 10M/100M self-adaptive Ethernet port -IM/ND, IDM: 1 four-core M12 aviation plug |
| SD Card Storage | Built-in micro SD/SDHC/SDXC slot, up to 256 GB |
| Perkrovimo mygtukas | Support |
| Interface Type | Interpolate |
Funkcijos
| Susiejimo metodas | Upload to FTP, notify monitoring center, send email, trigger recording |
| Pagrindinės funckcijos | Motion detection, video tampering alarm |
| Išmaniosios funkcijos | Line crossing detection, Intrusion detection, Region entrance detection, Region exiting detection, Unattended baggage detection, Object removal detection, Object detection: detects faces and upload images Scene change detection, defocus detection |
Pagrindinis
| Product Dimension | Camera: Φ 78.8 mm × 81.6mm x 63.8 mm (3.1″ × 3.2″ x 2.5″) |
| Sistemos parametrai | PoE: 0.30 A to 0.20 A, max: 7.5 W DC: 0.83 A to 0.21 A, max: 7.5 W |
| Pakuotės dydis | 174 mm × 111 mm × 101mm (6.85″ × 4.37″ × 3.98″) |
| Product Weight | Approx. 330 g (0.7 lb.) |
| Darbo sąlygos | -30 °C to 75 °C (-22 °F to 167°F), humidity less than 95% or less (non-condensing) |
| Kalba | English, French, German, Russian, Italian, Korean, Portuguese, Spanish, Turkish, Polish, Czech |
| Pagrindinės funkcijos | Anti-flicker, heartbeat, mirror |
| Programinės įrangos nustatymas iš naujo | Support |
| Maitinimas | -ID: 9-36V& PoE (802.3af, 36 V to 57 V) -IDM: 9-36V& PoE (802.3af, 36 V to 57 V) -IM/ND: PoE (802.3af, 36 V to 57 V) |
| Maitinimas | -ID: Ø 5.5 mm coaxial power plug, DC power supply, or PoE power supply -IM/ND: four-core M12 aviation plug, PoE power supply |
| Cable Length | 50 cm |
Patvirtinimai
| Class | Class B |
| EMC | FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); |
| Saugumas | UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013); |
| Aplinkosauga | CE-RoHS (2011/65/EU); |
| Electrical Safety Protection | IP68 (IEC 60529-2013) |
| Automatika | EN50155-2017(EN 50155:2017, EN 50121-3-2:2016, IEC 60068-2-1:2007, IEC 60068-2- 2:2007, IEC 60068-2-30:2005, IEC 61373:2010); EN45545 (EN 45545-2:2013+A1:2015); E-MARK (ECE R10) |
| Svoris | 0,33 kg |
|---|---|
