Gaisro centralė Ajax EN54 Fire Hub 125732.315.WH (balta)
Preliminari mėnesinė įmoka nuo 32,38€ / 60 mėn.
982,81€(Kaina be PVM)1.189,20€(Kaina su PVM)
| Tipas: Gaisro centralė | |
| Modelis: Ajax EN54 Fire Hub Jeweller | |
| Modelio kodas: 125732.315.WH | |
| Spalva: Balta | |
| Palaikomi įrenginiai: iki 200 | |
| Tinklo jungtys: LAN, Wi-Fi, 2 x SIM (2G/4G) | |
| Ekranas: 10.1″ jutiklinis IPS | |
| Raiška: 1024 × 600 px | |
| Gaisro zonos: iki 40 | |
| Naudotojai: iki 200 | |
| Atsarginis maitinimas: Li-Ion 7.4 V baterija |
Neturime
Bendrieji duomenys
| Produkto pavadinimas | Ajax EN54 Fire Hub Jeweller |
| Tipas | Wireless control and indicating equipment (CIE) for fire alarm and intrusion protection systems |
| Atitikties standartai | EN 54-2, EN 54-4, EN 54-13, EN 54-21, EN 54-25, EN 50131 (Grade 2) |
| Ekranas | 10.1″ IPS capacitive touch screen, 1024 × 600 px, 50,000 hours backlight life |
| Interface language | English (default), configurable via Ajax apps |
| Pagrindinis maitinimo šaltinis | 110–240 V~, 50/60 Hz |
| Backup power supply | Li-Ion 7.4 V battery (5 or 10 Ah), battery life 24 to 72 hours depending on model |
| Autonomy | 24–72 h (based on installed EN54 internal battery) |
| Relių išėjimai | 2 (NC and NO), max resistive load: 2 A @ 30 V⎓, max 60 W in standby mode |
| External power supply (for relay) | 10–30 V⎓ |
| Communication protocols | Jeweller, Wings, TurboWings |
| Wireless range | Up to 1,800 m in open space |
| Maksimalus ERP | ≤ 25 mW |
| Užklausų intervalas | 12–300 s (adjustable) |
| Ryšio kanalai | Ethernet (100 Mbps), Wi-Fi (up to 72 Mbps), 2G/4G LTE with 2 × SIM slots (up to 4 providers) |
| Automatic switching | Between Wi-Fi, Ethernet, and cellular channels |
| Event transmission protocols | SurGard (Contact ID), SIA DC-09 (IP-based) |
| Zonos | Up to 40 |
| Ajax įrenginiai | Up to 200 (including up to 5 Fire ReX range extenders) |
| Fire detectors | Any Ajax fire detection devices with wireless connectivity |
| Vartotojai | Up to 200 |
| Saugumo grupės | Up to 25 |
| Patalpos | Up to 80 |
| Automatizavimo scenarijai | Up to 64 |
| Cameras/DVRs | Up to 36 Ajax NVRs, 25 Ajax cameras, or 100 third-party cameras (via RTSP) |
| Įvykių žurnalas | Up to 5,000 events, stored locally |
| Alarm management | Start/stop evacuation, mute/override buzzer, reset fire alarm, run tests |
| Zone management | Fire zones tab with grouped device status and test options |
| Sound and LED indicators | 40 LED indicators for fire zones, 6 LEDs for system states, built-in 60 dB buzzer |
| Vaizdinė verifikacija | Supports Ajax MotionCam and IP cameras for alarm confirmation and evidence |
| User authentication | Up to 200 personal codes, 200 duress codes, ISO14443-A (13.56 MHz) contactless access |
| Contactless access | Pass cards and tag key fobs (up to 200 devices); supports DESFire®, EV1, EV2 |
| Įrengimas | Tool-free with QR code; remote setup via Ajax apps |
| Maintenance | Hot-swappable backup battery, app-based diagnostics and remote service |
| Apsauga nuo sabotažo | Tamper alarm, device authentication, jamming detection, frequency hopping, loss detection within 36s, encrypted communication |
| Casing dimensions | — |
| Svoris | — |
| Komplektacija | Fire Hub Jeweller, installation accessories (battery sold separately) |
| Gamintojas |
|---|
