| Radio | 802.11ax/ac/n/a radio (Atheros 1.2GHz)Speed up to 1201MbpsFrequency Range: 5.1-5.8GHz Tx Power 26dBm±2Rx Sensitivity 1201Mbps: -67dBm@10% PER300M: -74dBm@10% PER54M: -78dBm@10% PER1M: -98dBm@10% PER |
| Antena | WIS-S516AX : 16dBi 120 degree dual-polarizedsector antenna |
| Fiziniai parametrai | Dimension: 395*100*90mmWeight: 0.77kgEnclosure: Weatherproof ASAESD Protection: 16kVLightning Protection: 8kVWorking Temp: -20 ~ 70°CStorage Temp: -40 ~85°CWorking Humidity: 10%~95% non-condensing |
| Sistemos parametrai | 24VDC, 0.75APower Consuption: 10W |
| Saugumas | Integrated Firewall WPA/WPA2;WPA-PSK/WPA2-PSK (AES/TKIP) Encryption; 64/128-bit WEP; |
| Sąsajos | 1x 10/100/1000 Base-T Ethernet (Gigabit LAN with Passive PoE) Reset |
| LED | Power:On/Off LAN:On/Off/Flashing WLAN:On/Off/Flashing RSSI Signal: 1,2,3 |
| Sertifikatai | CE, FCC,RoHS |
| LED | WIS-S516AX Quick Setup Guide Power Adapter with Passive PoE Mounting kits |
