Name: 6 prievadų, 4 PoE prievadų pramoninis komutatorius UTEPO UTP7304GE-POE 150W
SKU: SWITCHUTP7304GEPOE150
Price: 316.89 EUR
Availability: InStock

6 prievadų, 4 PoE prievadų pramoninis komutatorius UTEPO UTP7304GE-POE 150W

261,89€(Kaina be PVM)316,89€(Kaina su PVM)

2 SFP 1Gb prievadai
4 PoE Lan 1Gb prievadai
Perkėlimo pajėgumas 24Gbps
Palaiko IEEE802.3af/at
150W
PoE parametrai: 1 prievadas 60W HPoE，3 prievadai 30W PoE

Modelis	UTP7304GE-POE
Energijos įvestis	5pin green terminal, 2 groups DC input (reduntant power), 1 grounding terminal. Input power range:DC48V~57V
Energijos suvartojimas	Self comsumtion< 20W
Variniai prievadai	4* 10/100/1000Base-T PoE RJ45(Auto-MDI/MDI-X)
SFP prievadai	2*1000 Base-X SFP(Mini-GBIC)
Konsolės prievadai	1*RJ45-R232 serial port(115200,8,N,1)
Init mygtukas	Short press:restart.
Init mygtukas	>5s restore factory settings
Vienas paspaudimas, greitas skambutis	Default mode: No ring(can setup on web management).
Vienas paspaudimas, greitas skambutis	Ring mode: Fast ring with SFP X1 and X2
Persiuntimo signalizacija	Support relay alarm for power off, ports network link-off , ports PoE off （Set by Web Software）
Standartai ir protokolai	IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X, IEEE 802.1Q IEEE 802.1p IEEE 802.3ad , IEEE 802.1D, IEEE 802.1X
Perkėlimo pajėgumas	24Gbps
Paketų perkėlimo greitis	8.9Mpps
Perkėlimo rėžimai	Store and Forward
Paketų buferis	4Mbit
MAC adresų lentelė	8K MAC address table with auto learning function
Jumbo kadras	10K bytes
PoE standartai	T1 HPoE 60W max(also support 802.3af/at) ,T2～T4 802.3af/at 30W max
PoE linijų pora	T1:1/2(+),3/6(-).4/5(+),7/8(-)
PoE linijų pora	T2～T4:1/2(+),3/6(-) end-span
EMI	FCC Part 15,CISPR(EN55022) class A
EMC	Surge level-4 IEC61000-4-5
	ESD level-4 (8KV/10KV) IEC61000-4-2
	RS level-4 IEC61000-4-3
	EFT level-4 IEC61000-4-4
	CS level-3 IEC61000-4-6
	M/S level-5 IEC61000-4-8
Veikimo temperatūra	-40-75℃
Laikymo temperatūra	-40-85℃
Atsparumas drėgmei	5%-95%(Non-condensing)
Matmenys（L×W×H）	159mm×110mm×46.5mm
Svoris	1.5kg
Instaliacija	On desk.Din-rail.Wall hung
MTBF	330000 Hour
Ingress apsauga	IP40
Certifikatai	CE, FCC, ROHS
Programinės įrangos parametrai
Prievadų valdymas	Support Port Enable/Disable.
	Support Port Rate Settings.
	Support Port Full-duplex Mode.
	Support IEEE802.3x Flow Control.
	Support Port Name Change.
VLAN	Support 4K VLAN
	Support 802.1Q Protocol-Based VLAN.
	Support Port-Based VLAN.
QoS	Support QoS.
	Support 8-Level Priority management for switching.
	Support WRR.
	Support 820.1P and DSCP Priority.
Peržiurų valdymas	Support SNMP V1/V2/V3 Protocol.
Peržiurų valdymas	Support IGMP Snooping.
POE valdymas	Support Total Power Consumption Control.
	Support PoE ON/OFF.
	Support Single Port 60W max. Power Change and Port Output Priority.
Alarm signalo išvestis	Support relay alarm for power off, ports network link-off , ports PoE off
Apsauga	Support IP, MAC, Port, VLAN Combination and Binding.
	Support MAC address auto-learning, aging& filter.
	Support Port Isolation, Port Speed-Limited.
	Support RSTP.
	Support Fast-Ring.
	Support 5 groups of 8-Port trunk.
	Support RADIUS Authentication& 802.1X Authentication.
Sistemos valdymas	Support WEB Management, CLR Settings and telnet Settings.
	Support CLR Settings.
	Support FTP/TFTP/HTTP Web Upgrading.
	Support Flow Calculate.
	Support MAC address Form Search.
	Support IP Address, DNS Server Change
	Support Username & Password Change.
	Support History Record, Journal management.
	Support System settings Backup.
