Jeweller ryšio technologijaProprietary wireless communication technology to transmit commands, alarms, and events., Key features:, Two-way communication., Advanced sabotage protection., Block encryption featuring a dynamic key., Instant notifications., Remote control and configuration in Ajax apps., Learn more
Dažnių juostos866.0–866.5 MHz 868.0–868.6 MHz 868.7–869.2 MHz 905.0–926.5 MHz* 915.85–926.5 MHz 921.0–922.0 MHz, Depends on the sales region., * Certified according to UL/ULC standards.
Maksimali efektyvi spinduliuojama galia (ERP)up to 20 mW, Automatic power control to reduce power consumption and radio interference.
Radijo signalo moduliacijaGFSK
Radijo ryšio veikimo nuotolisup to 1,000 ft, Between the device and a hub (or a range extender) in an open space., Calculate the radio communication range at the facility
Šifruotas ryšysAll stored and transmitted data are protected by block encryption featuring a dynamic key.
Dažnių šuoliaiTo prevent radio interference and jamming., Learn more
Pagrindinės savybės
Mygtukų skaičius4, System arming button., System disarming button., Night mode button., Panic button.
Group managementA user can select a security group that the key fob manages.
Assigning to a userWhen a key fob is assigned to a user, its events are sent to Ajax apps under the user’s name. The key fob has the same security mode management rights as the user.
Apsauga nuo atsitiktinio paspaudimolong or double press, Available on key fobs with the firmware version 5.54.1.0 or higher manufactured from March 19, 2020.
Maitinimas
Baterija1 × CR2032, Pre-installed.
Tipastype C
Pilna baterijos talpa225 mAh
Nominali įrenginio darbinė įtampa3 V⎓
Ramioji įrenginio srovės sąnauda esant nominaliai įtampai0.7 μA
Maksimali įrenginio srovės sąnauda esant nominaliai įtampai26 mA
Apskaičiuotas baterijos veikimo laikasup to 5 years
GamintojasRenata Panasonic, UL listed.
Korpusas
Matmenys2.56″ × 1.46″ × 0.39″
Balto įrenginio svoris0.46 oz
Juodo įrenginio svoris0.44 oz
Darbo temperatūros diapazonasfrom −13 °F to 122 °F, Temperature range from 32 °F (0 °C) to 120 °F (+49 °C) is certified according to UL/ULC standards.
Drėgmėup to 95%, Humidity of up to 93% is certified according to UL/ULC standards.
