24 prievadų komutatorius Ubiquiti Unifi USW-Pro-HD-24-PoE-EU
35,03€ / 60 mėn.
1.062,50€(Kaina be PVM)1.285,63€(Kaina su PVM)
| Tipas: Komutatorius | |
| Modelis: USW-Pro-HD-24-PoE-EU | |
| Prekės ženklas: Ubiquiti | |
| Prievadai: 22 x 2.5GbE RJ45 PoE++, 2 x 10GbE RJ45 PoE++, 4 x 10G SFP+, 2 x 25G SFP28 | |
| Energijos sąnaudos: 600W | |
| Tinklo lygis: Layer 3 | |
| Montavimas: 1U rack mount | |
| Perdavimo sparta: 230 Gbps | |
| Pralaidumas: 115 Gbps | |
| Perjungimo greitis: 171 Mpps | |
| VLAN palaikymas: Iki 1000 | |
| MAC adresų lentelė: 32 000 | |
| Buferis: 2 MB | |
| Darbinė temperatūra: -5…40°C |
Neturime
Pagrindinis
| Dydis | 442 x 400 x 44 mm (17.4 x 15.7 x 1.7″) |
| Portų išdėstymas | 2.5 GbE RJ45: 22 (All PoE++), 10 GbE RJ45: 2 (All PoE++), 10G SFP+: 4, 25G SFP28: 2 |
| Max. PoE Output | Up to PoE++ |
| Total PoE Availability | 600W |
| Atsparumas gedimams | DC Power Backup |
| Layer 3 | Yes |
| Form Faktorius | Rack Mount (1U) |
| Etherlighting™ | Yes |
| Perjungimo talpa | 230 Gbps |
| Bendras neblokuojantis pralaidumas | 115 Gbps |
| Perdavimo dažnis | 171 Mpps |
| Palaikomi VLAN | 1,000 |
| MAC adresų lentelės dydis | 32,000 |
| L3 lentelės dydis | ARP Entries: 12,000, IPv4 Routes: 12,000 |
| Paketų buferio dydis | 2 MB |
| Layer 3 Features | DHCP Server (Local Networks): Yes, DHCP Relay: Yes, Inter-VLAN Routing (Local Networks): Yes, Static Routing (Local Networks): Yes |
| Layer 2 Features | LACP Port Aggregation: Yes, STP & RSTP: Yes, QoS (DSCP): Yes, Pro AV Profiles (Play, Dante, Q-SYS, NDI, SDVoE, Shure, AES67, Crestron): Yes, Advanced IGMP Configuration (Querier, Fast Leave, Router Port): Yes, IGMP Snooping: Yes, 802.1X Control: Yes, MAC-Based ACLs & Device Isolation: Yes, DHCP Snooping & Guarding: Yes, Egress Rate Limit: Yes, Flow Control: Yes, Storm Control: Yes, Multicast & Broadcast Rate Limiting: Yes, MAC Address Blocking: Yes, IP-Based ACLs & Network Isolation: Yes, MAC-Based Port Restriction: Yes, Port Isolation: Yes, Port Mirroring: Yes, Jumbo Frames: Yes, LLDP-MED: Yes, Voice VLAN: Yes, Loop Protection: Yes |
| PoE Ports | PoE++: 24 |
| Max. PoE Wattage per Port by PSE | PoE: 15.4W, PoE+: 32W, PoE++: 64W |
| Maks. energijos sunaudojimas | 60W (Excluding PoE Output), 660W (Including PoE Output) |
| Maitinimo metodas | (1) Universal input, 100—240V AC, 50/60 Hz, (1) USP RPS DC input |
| Maitinimo įvesties metodas | AC input |
| Maitinimas | AC/DC, internal, 660W |
| Palaikomos įtampos diapazonas | 100—240V AC |
| Valdymas | Ethernet: AR |
| Svoris | Without mounting brackets: 6.2 kg (13.7 lb), With mounting brackets: 6.3 kg (13.9 lb) |
| Korpuso medžiaga | SGCC steel |
| Palaikomas stovo gylis | 600 – 1,200 mm (23.6-47.2″) |
| LCM ekranas | 1.3″ Touchscreen |
| Aplinkos darbinė temperatūra | -5 to 40° C (23 to 104° F) |
| Aplinkos darbinė drėgmė | 10 to 90% noncondensing |
| Sertifikatai | CE, FCC, IC |
| Etherlighting™ | Ethernet: Yes, SFP+: Yes, SFP28: Yes |
| Svoris | 6,6 kg |
|---|---|
| Gamintojas |
