16 prievadų, 16 PoE komutatorius Utepo UTP3-GSW1604S-MTP250

Modelis

UTP3-GSW1604S-MTP250

Variniai portai

16*10/100/1000Base-T PoE RJ45(Auto-MDI/MDI-X)

SFP portai

4*1000 Base-X SFP(Mini-GBIC)

Valdymo portas

1*RJ45-R232 serial port(115200,8,N,1)

Paleidimo mygtukas

Short press:restart;

>5s Press: restore factory settings.

Tinklo standartas

IEEE802.3 , IEEE802.3u, IEEE802.3ab, IEEE802.3Z, IEEE802.3X, IEEE 802.1Q, IEEE 802.1p IEEE 802.3ad , IEEE 802.1D, IEEE 802.1X

Perjungimo pajėgumas

40Gbps / non-blocking

Paketų persiuntimo greitis

29.8Mpps

Store and Forward

Paketų buferis

12Mbit

MAC adresų lentelė

16K MAC address table with auto learning function

Jumbo rėmas

10K bytes

PoE standartas

IEEE802.3af 15.4W, IEEE802.3at 30W

PoEgalio perdavimo metodas

PoE linijos pora

1/2(+)，3/6(-)

Įvesties įtampa

Internal power adapter

AC 100-240V 50/60Hz

Suvartojimas

<250W (PoE consumption)

PoE budget: 230W

Viršįtampiai

6KV

Execute: IEC61000-4-5

Elektrostatinės iškrovos apsauga

6KV: Contact discharge

8KV: Air discharge

Execute: IEC61000-4-2

Darbo temperatūra

-10-50℃

Saugyklos temperatūra

-40-85℃

Drėgmė

5%-95%(Non-condensing)

Matmenys（I×P×A）

442mm×286mm×44mm

Svoris

3.859kg

Sertifikatai

CE, FCC, ROHS

Programinės įrangos parametrai

Sąsajų valdymas

Logic Interface

Support port isolation

Support port rate settings

Support port storm suppression

Support IEEE802.3x flow control

Support port traffic statistics

Support port adaptation

Loopback detection

VLAN

VLAN Partition

VLAN based on port, VLAN based on MAC

Private VLAN, multicast VLAN

VLAN Communication

VLAN intercommunication

VLAN isolation

VLAN Port Type

Access, Trunk, GVRP, QinQ

MAC

Static MAC

MAC Black hole

Dynamic MAC

MAC address aging configuration

MAC address learning limit

Multicast MAC

Static Multicast MAC address

Grįžtamo ryšio apsauga

STP/RSTP, ERPS v1，v2（G.8032）, y.1731 CCM

IP sąvybės

IP address : Classful IP address, classless IP address

ARP

IPv6 address configuration

DHCP

Host DHCP service

DHCP pool

DHCP relay

DHCP snooping option 82

IGMP sąvybės

IGMP snooping

GMRP

QoS

Support 802.1p CoS/DSCP priority

Support 8-Level priority management for switching

Support WRR, PQ, DRR, WFQ, ACL based on ports and queues

PoE valdymas

Support total power consumption control

Support PoE ON/OFF

Support single port 30W max. Power change and port output priority

Saugos pobūdis

802.1x

IEEE 802.1X Port/MAC based authentication, Radius

Support MAC address auto-learning, aging& filter

Support port isolation, port speed-limited

ACL

Basic ACL, advanced ACL

System Log

Local system log management

Remote System Log Management

Mirroring

Port mirroring

Sistemos valdyas ir priežiūra

Support WEB management, configuration through Telnet, SSH, Tracert v4

SNMPv1/v2/v3 management

NTP

Link layer discovery protocol (LLDP)

IPv6

Dual IPv4/IPv6 stack

Ping IPv6, WEB IPv6

DHCPv6 snooping, DHCPv6 client

IPv6 ACL, IPv6 SSH

IPv6 neighbor discovery (ND)
